Safety Gas Circulation
Built-in safety and venting valves ensure safety when printing.
Air Filtration System
Environmentally friendly, avoiding secondary pollution.
Double Sealed Piston
Ensures the sealing of the metal powder storage room.
Software
Self-developed full-process software system.
| Build Volume | 430 × 340 × 400 mm 16.93 × 13.39 × 15.75 in |
| Build Chamber Size | 440 × 350 × 440 mm 17.32 × 13.78 × 17.32 in |
| Laser Type | Yb-fiber Laser, 1 x 500 w / 2 x 500 w |
| Precision Optics | 4 F-theta-lenses |
| Layer Thickness | 20μm - 100μm |
| Max. Scanning Speed | 6 m/s |
| Inert Gas | Argon / Nitrogen |
| Power | 380 vAC, 50 Hz |
Machine Dimensions | 2950 x 1350 x 2200 mm 116.14 x 53.15 x 86.61 in |
| Machine Weight | 2200 kg |
Consult with your sales representative for confirmation of current offering.
