Smart Manufacturing
· Original galvanometer scanning path planning and exposure strategy algorithm.
· To achieve closed-loop temperature control, adjust PWM pulse width output in real-time using temperature sensor data to keep resin temperature within the desired range.
| Build Volume | 380 × 380 × 250 mm / 14.9 × 14.9 × 9.8 in 380 × 380 × 150mm / 14.9 × 14.9 × 5.9 in |
| Accuracy | Dimension x≤100 mm: ±0.1 mm Dimension ＞100 mm: ±0.1% x Dimension |
| Laser Power | 1500 mW |
| Scanning Speed | 6-10 m/s |
| Control Software | UnionTech™ RSCON |
| Data Interface | .stl |
| Network | Ethernet, IEEE802.3, TCP/IP |
| Rated Power | 2.6 kVA |
| Systems Control | Closed-loop |
| Temperature Range | 22–26 °C (72–79 °F) |
| Relative Humidity | < 40% |
| Resin Vat | Fixed |
| Machine Dimensions | 968 × 762 × 1722 mm 38.11 x 30.00 x 67.80 in |
| Machine Weight | 597 kg |
Consult with your sales representative for confirmation of current offering.
